Acura NSX, a pair of 2 Series Gran Coupes and a time machine | Autoblog Podcast #628

In this week’s Autoblog Podcast, Editor-in-Chief Greg Migliore is joined by West Coast Editor James Riswick and Road Test Editor Zac Palmer. This week, they’re driving a 2020 Acura NSX, two versions of the BMW 2 Series Gran Coupe (M235i and 228i) and the updated 2020 Honda Civic Si. Then, the gang gets to talking about what they’d drive in 1975 and 1985, along with plenty of other tangents. Finally, they wrap it up with news about the upcoming 2021 Acura TLX Type S and the fate of this year’s Woodward Dream Cruise.

Autoblog Podcast #628

Get The Podcast

  • iTunes – Subscribe to the Autoblog Podcast in iTunes
  • RSS – Add the Autoblog Podcast feed to your RSS aggregator
  • MP3 – Download the MP3 directly

Rundown

Feedback

Related Video:

2020 Acura NSX Suspension Deep Dive

The Acura NSX has been a special car as long as I’ve been in the business. The first one came out in 1990, the same year I started my career in automotive engineering. I vividly remember driving one briefly back then when we brought one in for benchmarking. I’d drive it again 22 years later when my previous employer bought a used 1991 example for a long-term test. Reader interest was sky-high and the car was still gorgeous, but the march of time and automotive engineering had clearly left it behind.

Then, in 2016, a second-generation NSX emerged, and it was packed with bleeding-edge thinking. It has a 3.5-liter twin-turbo V6, but this new NSX is a hybrid with an electric motor-generator sandwiched between the engine and its nine-speed DCT transmission. Two more electric motors – one for each wheel – power the front axle. There they can add traction, regenerate electricity under braking and dole out hyper-accurate levels of torque vectoring.

The car’s tire package was changed from Continental SportContact 5 to SportContact 6 tires in 2019, and numerous suspension re-tuning tweaks came along with them. The result is a lively and well-balanced car that is relentless when driven hard and a pussycat around town. Let’s see what they’ve got going on under there.

At first glance the 2020 Acura NSX appears to have dual wishbone front suspension. But we can’t tell for sure because that big two-piece brake rotor is in the way. The coil-over shock looks obvious, but a few odd details are apparent even from here.

This view also seems to indicate double wishbone suspension. But the pivot axis (green arrow) between the upper and lower ball joints looks wrong – it’s far too vertical. We’re missing something.

But I would be remiss if I failed to point out a few other things before we moved on. For one, the front drive axle confirms this to be an all-wheel-drive machine. Second, the forged aluminum damper mounting fork (yellow) that envelops the axle is mounted to the lower arm about 75% out from the arm’s inner pivot. The spring and damper motion ratio would be 0.75-to-1 relative to wheel movement, with a tiny reduction due to its lean angle.

Lastly, just look at the huge cast aluminum upright (white). Beautiful. Normally these are called hub carriers or steering knuckles, and I use the terms interchangeably. But the motorsports-derived term upright is normally applied when the piece is tall and, well, upright like this one.

This explains everything. The lower end of the upright is located by two forged aluminum links, each with its own outer ball joint. This type of suspension is often called Double Wishbone with Dual Lower Pivots even though we’re not technically looking at a wishbone.

That plastic piece is a fence that guides cooling air for the brakes. This will be your last look at it because I’m about to unbolt it.

The apparently too-vertical steering axis we saw earlier was a false first impression. The real lower pivot is a virtual point that lives in a physically impossible place where the lines of each link intersect. The angled forward link (yellow) locates the wheel in the fore-aft direction and absorbs longitudinal forces, while the rear lateral link (green) manages the camber angle and takes up cornering forces.

As you might expect, that virtual point moves about. Here’s what it looks like in action with the wheel off, and with the wheel on I can scrub the tire (and the driveway) to show where the pivot axis intersects the contact patch.

The point of all of this is to put the steering axis in a more favorable position relative to the tire’s contact patch in order to improve steering feel and lessen kickback and torque steer from the electric motors.

The actual pivot points do not reside where the nuts appear at the bottom. They live within the rubber bellows and the aluminum link. The two link ends are stacked and angled because they want them to be closer together than they could be if both were arrayed side-by-side on the same horizontal plane.

The arms and links of the front suspension are bolted to the chassis with what I call tie-bars, but I like the term dogbone used internally by Acura. The rear lateral link’s dogbone is spaced from the chassis by color-coded shims of varying thickness to achieve the desired camber angle.

The forged aluminum upper arm uses a low-mounted “in wheel” ball joint (yellow) similar to what we saw on the MX-5 Miata. That choice was made here for many of the same reasons: keep the hoodline and center of gravity low.

It’s mounted with a pair of dogbones, but the oddest bit may be that it serves as the attachment point for the front stabilizer bar’s end link (green). It’s mounted about 60% of the way out from the pivot for an approximate 0.6-to-1 motion ratio.

That non-standard link position does make it easy to locate the stabilizer bar itself in a quiet corner.

The NSX uses magnetorheological dampers (MR, but Mr. Dampers makes me smile) that are controlled by a system of suspension height sensors (yellow) at each corner, a steering angle sensor and g sensors. Probably others. The MR damper itself is made by BWI – the current patent holder – but Acura has developed its own control software and sensor suite.

MR dampers are continuously variable. The valving is fixed, but the viscosity of the damper fluid that passes through that valving can be varied proportionally by the application of an electrically-generated magnetic field. This gives them exceptionally quick reaction times.

Meanwhile, the upper mount pokes up to where we can see daylight and the yellow-painted underside of the hood.

The upper mount is laterally bolted to the chassis so the hoodline can be as low as possible. But it’s not a simple single-shear mount. Hidden stepped dowel extensions make it so the bolts aren’t doing everything on their own.

The brake master cylinder is mounted sideways and is operated by a stepper motor (yellow). This is common on hybrids and electric vehicles because they seek to prioritize magnetic “regenerative” braking for routine stops before using the pads and rotors. The brake pedal is attached to a smaller hydraulic cylinder to generate authentic feel and a pressure signal the system can use along with pedal position sensor data to calculate its response.

If this sounds like brake by wire, it absolutely is. And the feel is fantastic. Acura engineers told me the feeling can be so consistent that they had to program in an artificial “long pedal” to let an aggressive track-day driver know when the brakes were getting hot and losing effectiveness. If the by-wire system utterly fails – an exceedingly unlikely event – that smaller hydraulic cylinder attached to the pedal becomes the back-up system.

The brakes are made up of six-piston Brembo fixed calipers and two-piece rotors. Steel rotors are standard, but long-lasting lightweight ceramic ones that save 52 pounds of total unsprung mass are available as an option.

The calipers use an open-window design, but they have a bridge bolt stiffener (yellow) that must be removed before the pads can be extracted.

The initial view of the rear looks similar to what we first saw up front, except there are two calipers back here.

There’s another forged aluminum upper arm back here, and it’s mounted with dogbones that are deep-set into a vast ablation-cast aluminum section of the rear chassis.

The lower end of the rear damper (yellow) is mounted directly to the knuckle, which gives it a 1-to-1 motion ratio. This is a high mounting point above the rear axle, and the mounting bolt itself also anchors a bracket for the stabilizer bar end link (green), which means it has a 1-to-1 motion ratio, too.

Meanwhile, the rear position sensor’s strut (white) and its upper arm attachment are clearly visible.

The rear damper’s somewhat high lower mounting doesn’t indicate a short damper. Like most mid-engine cars, the rear of the NSX has high haunches. And the upper attachment is the same low-profile sideways-bolted mount we saw in the front.

The lower end of the rear knuckle is located by a pair of links, making this a multilink suspension that just happens to have one wishbone. Each carries a plastic brake cooling air deflector that must be removed so we can see better, but an unusual-looking nozzle (yellow) remains.

That noozle is the terminus of a tube that is enclosed within the forward half of the two-piece rear subframe, and the source of its air is a NACA duct located closer to the middle of the car.

The forward link is an angled semi-trailing link that is mainly concerned with the wheel’s fore-aft location. Its high mounting relative to its partner link is a sign of anti-squat rear geometry.

The lateral link’s dogbone attaches to the chassis in an angled orientation that makes its pivot axis (yellow) roughly line up with the forward link’s elevated pivot point.

As we saw up front, the rear wheel’s camber is adjusted via color-coded shims that are sandwiched between the dogbone and the chassis. This view also shows the overlapping interface of the two-piece subframe (green) at a point where both parts share a mounting bolt.

The toe link sits behind the rest, and it is quite a bit longer than its partners. Mid-engine cars are very responsive to steering inputs, so a healthy dose of roll understeer is necessary to keep them in line. This one has a turnbuckle (yellow) in the middle for easy static toe adjustments.

Here’s how this trio of links bolts to what is a tidy cast-aluminum knuckle.

No I didn’t forget about the rear stabilizer bar. Its pivots (yellow) are sandwiched between the rear subframe half and the chassis, and it arcs over the lateral link to meet its own connecting link (green). Try to ignore the bracket, which holds the air deflector I removed.

The main brake is a Brembo four-piston fixed caliper with an open pad-extraction window, while the smaller one is an electronically-controlled parking brake. The extremely flat central hat section of the two-piece brake rotor leaves no room for the in-hat drum parking brakes that less performance-minded cars tend to favor.

For their size, the Acura NSX’s wheel and tire package are admirably light. The 2019 and 2020 versions of the NSX use Continental SportContact 6 tires mounted on Y-spoke rims, a design that was chosen for its superior strength-to-weight ratio. It doesn’t hurt that they look fantastic, too. The 19-inch front rims are 8.5 inches wide, wear 245/35ZR19 tires and the assembly weighs just 41.5 pounds. The 20-inch rears are 11 inches wide, are shod with 305/30ZR20 tires and weigh just 54.5 pounds each.

There’s a lot of fascinating engineering hidden within the wheelhouses of the second-generation Acura NSX. And it all works beautifully. The 2020 NSX is an epic-handling machine that is also quite livable day-in day-out on the street. It is a thoroughly modern supercar, but it also plays homage to the original. It’s a pity we don’t see more of them out there on the road.

Contributing writer Dan Edmunds is a veteran automotive engineer and journalist. He worked as a vehicle development engineer for Toyota and Hyundai with an emphasis on chassis tuning, and was the director of vehicle testing at Edmunds.com (no relation) for 14 years.

Read more Suspension Deep Dives below and let us know which cars you’d like to see Dan put up onto the jack stand next …

Mazda MX-5 Miata Suspension Deep Dive

Toyota GR Supra Suspension Deep Dive

Porsche Taycan Turbo Suspension Deep Dive

Related Video:

Rare 1999 Acura NSX Zanardi Edition sells for $135,000

Somebody just bought a 1999 Acura NSX Zanardi Edition for $135,000 on Bring a Trailer. And to that we say, we’re jealous.

The Zanardi Edition is one of the more sought-after NSX models out there. Acura only ever sold 51 of them (named after racer Alex Zanardi), and they were sold during a time that nearly every NSX sold here was an NSX-T with the T-top. The hardtop Zanardi Edition features a number of performance improvements over a typical 1999 NSX.

Acura took a sizable chunk of weight out of the car. Versus a hardtop coupe, it’s about 54 pounds lighter. Compared to the more popular NSX-T, it’s 149 pounds lighter. This was done in a few ways, but the single biggest weight reduction was due to the power steering delete, making it more like the older NSXs that never had power steering. Lightweight BBS wheels, a lighter battery, single-pane rear glass and a lighter rear spoiler also helped to reduce weight.

It received a “racetrack-tuned suspension” that was considerably stiffer than the regular NSX. The shocks, springs and bushings were all revised, and Acura lowered the ride height (0.6 inch in front, 0.3 inch in rear). A stiffer and larger rear stabilizer bar was fitted, too.

The Zanardi Edition is rather distinctive looking because of its New Formula Red paint and dark BBS wheels. Acura added red stitching to the all black interior, and owners also got to use a sweet titanium shift knob. And of course, there’s a special edition plaque on the interior to officially declare it a Zanardi.

Acura did nothing to the engine or transmission. Therefore, it retains the 3.2-liter V6 (290 horsepower and 224 pound-feet of torque) and six-speed manual. We don’t get to see many Zanardi Editions go up for sale, but when they do, they get the big bucks. At 57,000 miles, this one is still on the low side, hence the $135,000 final bid.

A regular (albeit newer) 2004 NSX-T with 1,900 miles just sold for $133,000 earlier today. So yeah … NSX values don’t seem to be going anywhere but up these days.

Related video:

2020 Lamborghini Huracan Evo has the biggest price discount in America

Right now, buyers of the 2020 Lamborghini Huracan Evo are paying an average of $248,000 to drive the brand-new supercar off the dealer lot. That’s a hefty chunk of change, but it represents $16,269 off the car’s average $264,969 retail price, according to data provided to Autoblog by Truecar. That’s the largest discount in America on a new vehicle for the month of April, 2020 when judged by the dollar amount in savings off the sticker.

It’s not all that uncommon to see a lot of money taken off the sticker price of expensive luxury cars. This month, right behind the Lamborghini sits the 2019 BMW 8 Series with a few bucks shy of $11,000 in savings, which is hardly surprising. Though it’s a very sleek and entertaining car in some of its various incarnations, it hasn’t exactly proven to be a hot seller for the German automaker. The fact that there are a total of 15 (!) possible configurations probably doesn’t help. Two other BMWs, the 2020 7 Series ($10,164 in savings) and the 2019 i8 ($10,145) are also on the top 10 biggest discounts list.

In between that BMW sandwich are the 2019 and 2020 editions of the Acura NSX. It doesn’t really matter which one a buyer chooses to drive off the lot, either way lopping off more than $10,000 off the sticker price means the electrified supercar will cost just under $150k.

For a look at the best new car deals in America based on the percentage discount off their suggested asking prices, check out our monthly recap here. And when you’re ready to buy, click here for the Autoblog Smart Buy program, which brings you a hassle-free buying experience with over 9,000 Certified Dealers nationwide.

Related Video:

Race a Type S Concept and an 8-bit 1991 NSX in Acura’s new video game

Acura has unveiled a new mobile video game that features a variety of the brand’s notable cars from throughout the past three decades. The game is a spin-off of the brand’s “Beat That” commercial, and each level is programmed to look how video games looked when the different cars were in production. Players have the option to drive a race car, new and old Acura sports cars, or a crossover.

As part of the “Less Talk, More Drive” advertising campaign, Acura has released a series of commercials with the catchphrase, “Beat That.” They’re meant to demonstrate the company’s competitive spirit, and now Honda’s luxury brand has brought about a new way to get those fiery juices going. In the same week as the 2020 Chicago Auto Show, Acura has launched “Beat That” the mobile video game.

The game has six levels, each of which features a different car. Each race is a time trial, and the graphics are designed in a way that they match the years of the vehicles. Level 1 takes place at the 8-Bit Beach and features the 1991 Acura NSX. Level 2 takes place at the Warehouse Complex and features the 1998 Acura Integra Type R. Level 3 features a Snowy Summit stage an includes the 2020 Acura RDX A-Spec, while Level 3 is at a Grand Prix Circuit with the ARX-05 Daytona Prototype racecar. A 2020 NSX drives on the Super Skyway in Level 5, and the Type S Concept can be driven in a Cyber Tunnel in Level 6.

The only way to reach the next level within the game is to beat a specific lap time designated for each level. Users can play against themselves, or they can send challenges to friends through social media or other chat platforms. To compete against the best of the best, users can click on a leaderboard time and compete against ghost cars from the previous record laps.

To play the game on a mobile device, click here.

Acura shows off RDX accessories and 2020 NSX at SEMA

Following its successful season on the track, Acura speeds to SEMA to showcase a range of performance and race vehicles as well as a new line of concept A-Spec and Acura-branded accessories. Also on the luxury division’s stand will be the Type S Concept sedan and the 2020 NSX, both unveiled in Monterey Car Week in August, the latter wearing the classic Indy Yellow Pearl exterior paint.

Acura will show off its accessories on a 2020 RDX. Carbon fiber is the name of the game for its concept A-Spec treatment, used on the grille surround and on the lower front fascia, lower side sill, rear diffuser, lower doors and side mirror caps. There’s also a dark chrome theme on the rear Acura badge and A-Spec emblems. A-Spec is offered as a sport appearance trim on the RDX and is supposed to be part of all core Acura models in the future, so we’ll see whether this “concept” A-Spec packages eventually makes it way, whole or in part, to future variants.

The Acura Genuine Accessories to be shown on the same RDX, by contrast, are available IRL and include roof rails and crossbars, replete with a fork-mount bike attachment, 20-inch wheels with a custom dark tint finish, black lug nuts, black chrome emblems, a carbon-wrapped tailgate accent, illuminated A-Spec trim on the door sills and A-Spec carpet floor mats. It’s topped with a Thule cargo box.

The 2020 NSX will wear the Indy Yellow Pearl color in homage to the old Spa Yellow, one of two yellow paints offered with the first-generation version of the supercar and a favorite among collectors. It joins two generations of championship-winning NSX cars: the 1990 pre-production model driven by Hall of Famer Peter Cunningham to 14 wins and 26 podium finishes between 1991 and 2002, and the NSX GT3 Evo that has won multiple IMSA and SRO races. The carbon fiber-bodied supercar with custom-designed livery is offered for sale globally for around $525,000, Acura says.

Feast Your Eyes on This 1991 Acura NSX And Prepare Your Bank Account to be Emptied

It Only has 6,500 Miles

If you’ve always wanted to own an Acura NSX from the early 1990s, then you should buy this one from 1991 that’s currently on Bring A Trailer. This particular NSX is absolutely immaculate, with black paint and a black interior.

The car for sale was a Canadian car. It lived in its owner’s collection and was well taken care of. That collection resided in Saskatoon, Saskatchewan. From there it was imported to the U.S. in 2018.

The car is completely stock. It features 3.0-liter transversely-mid-mounted V6 making 270 hp and 210 lb-ft of torque. It’s rear-wheel drive and has a five-speed manual transmission. What makes this car special is its low miles. It has just 6,500 miles on its odometer. While there are probably other NSX’s out there that will go for less money, if you want a truly good one with low miles, this is an excellent choice.

The car is currently listed for sale in California. Due to the stringent emissions standards in the state, the seller has noted that the car will need to be sold to a buyer out of state if the buyer actually wants to drive the car.

As of the time of the writing of this article, the bid is at $34,000. We would assume that the price will only go up from here. The auction still has three days left.

Acura Honors the 30 Year Anniversary of the NSX Debut in Chicago

The Shot Heard ‘Round the World

In 1989, Acura debuted the NSX supercar and changed the automotive industry. The NSX, then debuted as the NS-X Concept, changed the way people thought about supercars. It came with world’s first all-aluminum monocoque chassis, had titanium connecting rods, and was built to a different standard than the competition. It was the first exotic supercar from Japan and the first supercar you could easily drive daily.

To commemorate the 30-year marker, Acura celebrated the car in Chicago and put together a video. It features the first NSX and the most recent iteration. The commemorative video hits the high points of the model’s debut and showcases some seriously beautiful cars side by side.

[embedded content]

Acura had several different influential members at the Chicago Auto Show to discuss the NSX and its impact. Jon Ikeda, Vice President and General Manager of Acura, was there when the NSX first hit the world stage.

Before NSX, it was always assumed that supercar performance came at the price of a comfortable interior and everyday drivability,” said Ikeda. “NSX shattered those notions, and raised the bar on every other exotic and supercar maker, with the effects still felt today. NSX was a huge inspiration and one of the major reasons I was drawn to join Acura nearly 30 years ago.

The current generation NSX carries on the original car’s mission. The car pushes the performance envelope with a hybrid powertrain and Sport Hybrid Super-Handling All-Wheel Drive. It has a hybrid twin-turbocharged, mid-mounted V6 engine. It can also operate in full EV mode, and it’s the only supercar built in America.

Acura shows no signs of slowing down, and that’s a very good thing for enthusiasts everywhere. It will keep making the NSX better. Hopefully, in another decade, Acura will celebrate the 40-year anniversary.

2019 Acura NSX Gets A Refresh

Acura’s Mid-engine Hybrid Receives Chassis Upgrades, New Color & More Standard Features

The 2019 Acura NSX receives the model’s first refresh, after its market debut some 2 years ago. The refresh is relatively minimalist in nature – as far as these kind of things go – with the mid-engine hybrid AWD supercar benefiting from some chassis tweaks, aesthetic enhancements and introduction of more standard equipment. The NSX retains the 573-horsepower, twin-turbocharged V6 with 3 electric motors and 9-speed DCT used in previous years.

The NSX debuted with its new swag at ‘The Quail, A Motorsports Gathering’ event on the Monterey Peninsula in California. Most notable on display, was the new ‘Thermal Orange’ paint color option ($750 USD). Other exterior changes include the front grille upper section now being finished in the main body color (previously chrome).

Arguably, the most important changes come in the form of improvements to the chassis which include new Continental SportContact tires, a stiffer suspension setup and calibrations to the vehicle’s software, which directs the SH-AWD system, active dampers, electric power steering and stability control system.

Acura claims that all of these changes translate to a 26 percent and 19 percent stiffer front and rear anti-roll bar respectively, and ultimately provide better grip and more precise handling feedback to the driver. These upgrades were made in a direct response to the previous car’s tendency to be over-sensitive to weight transfer on corner entry, resulting in generally undesirable moments of oversteer.

Engineers modified chassis components, tires and software tuning to make NSX even more responsive to the will of the driver, elevating performance driving in all circumstances, from daily driving to the circuit. At the limit, the NSX’s balance, playfulness and controllability have improved, allowing the driver to more precisely modulate understeer and oversteer with subtle throttle inputs. – Acura Press Release

Acura further notes that the newest NSX will complete a lap of its home course, Suzuka Circuit, 2 seconds faster than before.

Now standard in the Acura NSX are the ELS premium audio system, power sport seats, navigation, proximity sensors and sport pedals – altogether costing $4,700 USD in options on the previous NSX. While the base price of the 2019 Acura NSX is $157,500 USD – $1,500 more than last year’s model – one could argue that the NSX is actually getting a price cut with the aforementioned $4,700 in options now being standard fare.

Acura NSX roadster finally on its way this year?

Autobild put together a slideshow forecasting various convertibles due to arrive from 2018 to 2023. The long-prophesied Acura NSX roadster graced the first slide, reportedly prepped for market launch later this year at a price of 200,000 euros. That’s about 13,000 euros more spendy than the hardtop, a relative bargain. Don’t call your Goldman private banker yet, though — that Autobild slide is likely as close as any of us will get to said roadster this year.

We’ve been doing the hokey pokey with the droptop NSX for at least six years now. In 2012 an eager enthusiast corps thought a European patent might have revealed the convertible supercar, only to realize it was Acura protecting Tony Stark’s screen gem in The Avengers (pictured). In 2016, Autocar reported that Honda viewed the NSX as a platform for experiment and tests of developing technology that “help [Honda] understand where the brand is going.” Those brand explorations meant Honda was “contemplating convertible, lightweight, non-hybrid and all-electric versions.”

In 2017, Internet snoopers happened on patent images for a droptop coupe first dubbed the “Baby NSX,” then potentially the ZSX after more snooping dug up a trademarked name. Even though production plans for a “Small NSX” actually did exist, dated to before 2008, the Small NSX/BabyNSX/ZSX turned out to be the Honda Sports Vision GranTurismo entry when Honda couldn’t make a business case for the genuine article.

Here we are staring down the same wishing well. Last year Acura sold 137 NSXs in the U.S. through the end of Q1, and so far this year only 67 coupes found buyers in that time. We know the NSX is a halo car, but halos work to best effect when they’re visible. So all we know now is that the talented hybrid would do well with any variant that would get it more visibility, of the top-down kind, the Type R kind, perhaps a road-legal, non-hybrid GT3 kind, or any other.

Related Video:

Acura NSX ScienceofSpeed Dream Project brings another wing to SEMA

Acura rolled into SEMA last year with its non-hybrid NSX GT3 race car, that FIA spec-series competitor pulled to Vegas on a trailer behind a GT3-themed Acura MDX. Sticking with the GT3 theme this year but going road-legal, Acura worked with Arizona-based ScienceofSpeed on a GT3 package that NSX owners can put in driveways. The result is the lower, more powerful, more wing-y NSX “Dream Project.”

Liquid-cooled injecting for the twin-turbo boosts output, adding 37 horsepower for a total of 610, and another 31 pound-feet of torque to register 507. A lightweight steel exhaust sheds 16 pounds and bestows those magnified numbers with magnified bass. A custom suspension drops the coupe by a little more than an inch, a custom iLIFT suspension add-on automatically raises the front axle two inches if the NSX detects a hurdle.

The ScienceofSpeed aero kit includes all you’d expect from the alphanumeric “GT3:” front strakes, wider rocker panels, larger rear diffuser, a rear wing, gold powdercoated carbon ceramic Brembo brakes, and wider Pirelli Trofeo R tires wrapped around Advan GT forged wheels. Drench the package in two-tone Andaro Nouvelle Blue Pearl and gloss black roof, and the NSX Dream Project’s ready to be driven from climate-controlled garage, to parking-lot car show, back to climate-controlled garage. If the owner decides to test a limit or two, Recaro Pole Position seats and a gaugeART OLED display will keep him locked in and informed.
